Deutz-Fahr Agrotron 106


Deutz-Fahr Agrotron 106 tractor photo
1997 - 2001
Agrotron Series
Row-Crop tractor
Series:Agrotron 106Agrotron 110
Production
Manufacturer:Deutz-Fahr
Type:Row-Crop tractor
Deutz-Fahr Agrotron 106 Power
Engine:100 hp
74.6 kW
Deutz-Fahr Agrotron 106 Engine
Deutz 4.8L 6-cyl diesel
Fuel tank:68.7 gal
260.0 L
Engine details ...
Mechanical
Chassis:4x4 MFWD 4WD
Cab:Cab standard with air-conditioning.
Transmissions:24-speed four-speed power shift
 40-speed creeper
Transmission details ...
Photos
No photos of the Deutz-Fahr Agrotron 106 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Pump flow:21.9 gpm
82.9 lpm
Tractor hitch
Rear Type:III/II
Rear lift:13713 lbs
6220 kg
 20371 lbs
9240 kg *Optional
Front Hitch:II
Front lift:6614 lbs
3000 kg
Power Take-off (PTO)
Rear RPM:540/1000
Front RPM:1000
Dimensions & Tires
Wheelbase:104.3 inches
264 cm
Weight:11047 lbs
5010 kg
Front tire:16.9R24
Rear tire:18.4R38
Full dimensions and tires ...
