Deutz-Fahr Agrotron 105


Deutz-Fahr Agrotron 105 tractor photo
1997 - 2001
Agrotron Series
Row-Crop tractor
Production
Manufacturer:Deutz-Fahr
Type:Row-Crop tractor
Deutz-Fahr Agrotron 105 Power
Engine:100 hp
74.6 kW
Deutz-Fahr Agrotron 105 Engine
Deutz 4.8L 6-cyl diesel
Fuel tank:50.2 gal
190.0 L
Engine details ...
Mechanical
Chassis:4x4 MFWD 4WD
Transmissions:24-speed three-speed power shift
 36-speed creeper
Transmission details ...
Photos
No photos of the Deutz-Fahr Agrotron 105 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Pump flow:17.4 gpm
65.9 lpm
Tractor hitch
Rear lift:13715 lbs
6221 kg
Power Take-off (PTO)
Rear RPM:540/1000
Dimensions & Tires
Wheelbase:104.3 inches
264 cm
Weight:9922 lbs
4500 kg
Front tire:380/70R28
Rear tire:480/70R38
Full dimensions and tires ...
