Deutz-Fahr DX 3.50


Deutz-Fahr DX 3.50 tractor photo
1984 - 1995
DX 3 Series
Utility tractor
Series map:
DX 3.30
DX 3.50
DX 3.60
40.3kw
45.5kw
48.5kw
Production
ManufacturerDeutz-Fahr
Utility tractor
Built in Germany
Deutz-Fahr DX 3.50 Transmissions
8-speed partially synchronized
12-speed partially synchronized
16-speed two-speed power shift
24-speed two-speed power shift
Transmission details ...
Deutz-Fahr DX 3.50 Power
Engine61 hp
45.5 kW
Mechanical
Two- or four-wheel drive
Differential lockmechanical rear
Power steering
ROPS Brakesmechanical disc
Cab Brakeshydraulic disc
Four-post ROPS with canopy. StarCab optional.
Photos
No photos of the Deutz-Fahr DX 3.50 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
ROPS Fuel19.8 gal
74.9 L
Cab Fuel22.5 gal
85.2 L
Hydraulic system4 gal
15.1 L
 7.5 galOptOptional
28.4 L
Hydraulics
Typeopen center
Capacity4 gal
15.1 L
 7.5 galOptOptional
28.4 L
Pressure2538 psi
175.0 bar
Rear valves1 to 3
Front valves2 OptOptional
Pump flow13.5 gpm
51.1 lpm
Tractor hitch
Rear TypeII
Controlposition and draft control
Rear lift5291 lbs
2399 kg
Front HitchII *Optional. Not available with StarCab.
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540 (1.375)
Front PTOindependent *Optional. Not available with StarCab.
Clutchdry disc
Front PTO Type1000
Dimensions & Tires
2WD Wheelbase79 inches
200 cm
4WD Wheelbase82 inches
208 cm
Weight6018 to 7319 pounds
Front tire7.50x16
2WD Rear tire16.9x30
Full dimensions and tires ...
References
DX 3.50 references literature
DX3 StarCab published in 1985, by Deutz-Fahr
DX3 StarCab published in 1992, by Deutz-Fahr
DX3.10-DX3.30-DX3.50-DX3.70-DX3.90 published in 1985, by Deutz-Fahr
