Deutz-Fahr DX 3.30


Deutz-Fahr DX 3.30 tractor photo
1984 - 1995
DX 3 Series
Utility tractor
Series map:
DX 3.10
DX 3.30
DX 3.50
34.3kw
40.3kw
45.5kw
Production
ManufacturerDeutz-Fahr
Utility tractor
Built in Germany
Deutz-Fahr DX 3.30 Transmissions
8-speed partially synchronized
12-speed partially synchronized
16-speed two-speed power shift
24-speed two-speed power shift
Transmission details ...
Deutz-Fahr DX 3.30 Power
Engine54 hp
40.3 kW
Mechanical
Two- or four-wheel drive
Differential lockmechanical rear
Power steering
Mechanical disc brakes
Four-post ROPS with canopy.
Photos
No photos of the Deutz-Fahr DX 3.30 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel19.8 gal
74.9 L
Hydraulic system4 gal
15.1 L
 7.5 galOptOptional
28.4 L
Hydraulics
Typeopen center
Capacity4 gal
15.1 L
 7.5 galOptOptional
28.4 L
Pressure2538 psi
175.0 bar
Rear valves1 to 3
Front valves2 OptOptional
Pump flow13.5 gpm
51.1 lpm
Tractor hitch
Rear TypeI
Controlposition and draft control
Rear lift5291 lbs
2399 kg
Front HitchII OptOptional
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540 (1.375)
Front PTOindependent OptOptional
Clutchdry disc
Front PTO Type1000
Dimensions & Tires
2WD Wheelbase79 inches
200 cm
4WD Wheelbase82 inches
208 cm
Weight6018 to 6459 pounds
Front tire7.50x16
2WD Rear tire16.9x30
Full dimensions and tires ...
References
DX 3.30 references literature
DX3 StarCab published in 1985, by Deutz-Fahr
DX3 StarCab published in 1992, by Deutz-Fahr
DX3.10-DX3.30-DX3.50-DX3.70-DX3.90 published in 1985, by Deutz-Fahr
