Deutz-Fahr D 6507


Deutz-Fahr D 6507 tractor photo
1982 - 1984
07 Series
Utility tractor
Series:D 6207D 6507D 6807
Production
Manufacturer:Deutz-Fahr
Type:Utility tractor
Deutz-Fahr D 6507 Power
Engine:62 hp
46.2 kW
Deutz-Fahr D 6507 Engine
Deutz 3.8L 4-cyl diesel
Fuel tank:23.8 gal
90.1 L
Engine details ...
Mechanical
Chassis:4x2 2WD
 4x4 MFWD 4WD
Steering:power
Brakes:mechanical disc
Cab:Four-post ROPS. Cab available with heat.
Transmission:9-speed synchronized
Transmission details ...
Hydraulics
Type:open center
Pressure:2538 psi
175.0 bar
Pump flow:10.6 gpm
40.1 lpm
Tractor hitch
Rear Type:II
Control:position and draft control
Rear lift:5300 lbs
2404 kg
Front Hitch:I
Front lift:3372 lbs
1529 kg
Power Take-off (PTO)
Rear PTO:independent
Rear RPM:540
Front PTO:independent
Front RPM:1000
Dimensions & Tires
2WD Wheelbase:84.3 inches
214 cm
4WD Wheelbase:86.2 inches
218 cm
Weight:6349 to 7055 pounds
Front tire:7.50-18
2WD Rear tire:16.9-30
Full dimensions and tires ...
