Deutz-Fahr D 5207
|
|
| Production | |
| Manufacturer | Deutz-Fahr |
| Utility tractor | |
| Deutz-Fahr D 5207 Engine | |
| Deutz 2.8L 3-cyl diesel | |
| Fuel tank | 18.5 gal 70.0 L |
 Engine details ... | |
| Deutz-Fahr D 5207 Transmission | |
| 8-speed synchronized | |
 Transmission details ... |
| Deutz-Fahr D 5207 Power | |
| Engine | 51 hp 38.0 kW |
| Mechanical | |
| Two- or four-wheel drive | |
| Power steering | |
| Mechanical disc brakes | |
| Four-post ROPS. Cab available with heat. |
| Photos | |
 | |
 Deutz-Fahr D 5207 photos... | |
| Hydraulics | |
| Type | open center |
| Pressure | 2538 psi 175.0 bar |
| Pump flow | 9.2 gpm 34.8 lpm |
| Tractor hitch | |
| Rear Type | II/I |
| Control | position and draft control |
| Rear lift | 5300 lbs 2404 kg |
| Front Hitch | I |
| Front lift | 3372 lbs 1529 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540/1000 |
| Front PTO | independent |
| Front PTO Type | 1000 |
| Dimensions & Tires | |
| 2WD Wheelbase | 79.1 inches 200 cm |
| 4WD Wheelbase | 81.1 inches 205 cm |
| Weight | 5952 to 6592 pounds |
| Front tire | 7.50-16 |
| 2WD Rear tire | 14.9-28 |
 Full dimensions and tires ... | |
| References | |
 | |
| D5207C - D6507C - D7807C published by Deutz-Fahr |
