Deutz-Fahr Intrac 2005


Deutz-Fahr Intrac 2005 tractor photo
1974 - 1975
Intrac 2000 Series
Tool Carrier tractor
Series:Intrac 2004Intrac 2005Intrac 2006
Production
Manufacturer:Deutz-Fahr
Type:Tool Carrier tractor
Deutz-Fahr Intrac 2005 Power
Engine (gross):84.8 hp
63.2 kW
Deutz-Fahr Intrac 2005 Engine
Deutz 4.7L 5-cyl diesel
Fuel tank:37 gal
140.0 L
Engine details ...
Mechanical
Chassis:4x4 4WD
Steering:power
Brakes:drum
Cab:Cab standard.
Transmission:hydrostatic
Transmission details ...
Photos
No photos of the Deutz-Fahr Intrac 2005 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Tractor hitch
Rear Type:II
Rear lift:7055 lbs
3200 kg
Front Hitch:I
Front lift:3527 lbs
1599 kg
Power Take-off (PTO)
Rear RPM:540/1000 (1.375)
Engine RPM:540@2300
1000@2300
Front RPM:1000 (1.375)
Engine RPM:1000@2300
Dimensions & Tires
Wheelbase:98.4 inches
249 cm
Weight:5512 lbs
2500 kg
Front tire:12.5-20
Rear tire:12.5-20
Full dimensions and tires ...
