    John Deere 5210

    John Deere 5210 tractor photo
    1998 - 2001   5010 Utility Series
    Utility tractor
    Previous model:John Deere 5200
    Next model:John Deere 5220
    Larger:John Deere 5310






    Production:

    Manufacturer:John Deere
    Factory:Augusta, Georgia, USA
    Original price (USD):$21,795 (2001)


    John Deere 5210 Engine:

       John Deere 2.9L 3-cyl diesel
    full engine details ...


    Capacity:

    Fuel:18 gal [68.1 L] (ROPS)
     23 gal [87.1 L] (cab)


    3-Point Hitch:

    Rear Type:I/II
    Rear lift (at 24"/610mm):3,374 lbs [1530 kg]


    Power Take-off (PTO):

    Rear PTO:independent
    Rear RPM:540
     540/540E (SyncShuttle)


    Dimensions & Tires:

    Wheelbase:80.7 inches [204 cm]
    Weight:4205 to 5650 pounds
    Front tire:6.5-16
    Rear tire:13.6-28 (2WD)
    full dimensions and tires ...


    5210 Serial Numbers:

    Location:The tractor's serial number plate is on the right side of the frame, above the front axle.
    1998: 120000
    1999: 220001
    2000: 320001
    2001: 420001

    how to read serial numbers...



    Links:

    Temperature sensor: potential cold-start advance sensor failure leading to a no-start condition


    John Deere 5210 Power:

    Engine:53 hp [39.5 kW]
    PTO (claimed):45 hp [33.6 kW]
    PTO (tested):46.16 hp [34.4 kW]
    power test details ...


    Mechanical:

    Chassis:4x2 2WD
     4x4 MFWD 4WD (optional)
    Steering:hydrostatic power
    Brakes:hydraulic wet disc
    Cab:Two-post ROPS. Cab optional.


    Hydraulics:

    Type:open center
    Pressure:2855 psi [196.9 bar]
    Valves:5
    Pump flow:11.4 gpm [43.1 lpm]
    Total flow:18.2 gpm [68.9 lpm]
    Steering flow:6.8 gpm [25.7 lpm]
    Steering press.:1955 psi [134.8 bar]


    Electrical:

    Ground:negative
    Charging system:alternator
    Charging amps:40 (ROPS)
     60 (cab)


    Battery:

    Number:1
    Cold-cranking amps:700
    Volts:12
    Group:28H (ROPS)
     31 (cab)
