Kubota L5030


Kubota L5030 tractor photo
2003 - 2007
L30 Series
Compact Utility tractor
Series map:
L4630
L5030
47.2hp
52.2hp
Production
ManufacturerKubota
Compact Utility tractor
Built in Japan
Variants
L5030GSTGlide-shift
L5030HSThydrostatic
L5030HSTChydrostatic with cab
Kubota L5030 Engine
Kubota 2.4L 4-cyl diesel
Fuel tank11.4 gal
43.1 L
Engine details ...
Kubota L5030 Transmissions
hydrostatic
12-speed power shift
Transmission details ...
Kubota L5030 Power
Engine (gross)52.2 hp
38.9 kW
Engine (net)50 hp
37.3 kW
Gross PTO (claimed)44 hp
32.8 kW
Hydro PTO (claimed)42.5 hp
31.7 kW
PTO (tested)45.89 hp
34.2 kW
Performance test details ...
Mechanical
Four-wheel drive
Power steering
Wet disc brakes
Two-post ROPS. Grand Cab optional
Hydraulics
Typeopen center
Valves3 OptOptional
Pump flow9.8 gpm
37.1 lpm
Total flow14.7 gpm
55.6 lpm
Steering flow4.9 gpm
18.5 lpm
Tractor hitch
Rear TypeII/I
Controlposition control with optional draft control
Rear lift (at 24"/610mm)2980 lbs
1351 kg
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540 (1.375)
Engine RPM540@2550
Mid PTOindependent OptOptional
Mid PTO Type2000
Dimensions & Tires
Wheelbase75.4 inches
191 cm
Weight3705 to 4090 pounds
Front tire9.5-16
Rear tire14.9-26
Full dimensions and tires ...
Kubota L5030 attachments
snowblower
blade
front-end loader
backhoe
Attachment details ...
L5030 Serial Numbers
Location:Serial number decal on the left side of the tractor frame, above the front axle.
Electrical
Groundnegative
Charging systemalternator
ROPS Charging amps45
Cab Charging amps60
Battery volts12
References
L5030 references literature
Grand L 30 Series published in 2004, by Kubota*
*Publication contains known errors.
