Kubota M4800SU
| | 2004 - 2010 |
| Compact Utility tractor |
|
| Production |
| Manufacturer: | Kubota
|
| Type: | Compact Utility tractor
|
| Kubota M4800SU Power |
| Engine: | 50 hp
37.3 kW
|
| PTO (claimed): | 43 hp
32.1 kW
|
| Mechanical |
| Chassis: | 4x2 2WD
|
| Final drives: | inboard planetary
|
| Differential lock: | mechanical rear
|
| Steering: | power
|
| Brakes: | wet disc
|
| Cab: | Two-post folding ROPS
|
| Transmission: | 8-speed partially synchronized
|
 Transmission details ... |
| Photos |
| No photos of the Kubota M4800SU are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Hydraulics |
| Type: | open center
|
| Valves: | 2*Optional
|
| Pump flow: | 11 gpm
41.6 lpm
|
| Total flow: | 17.1 gpm
64.7 lpm
|
| Tractor hitch |
| Rear Type: | II/I
|
| Rear lift (at ends): | 4200 lbs
1905 kg
|
| Rear lift (at 24"/610mm): | 3310 lbs
1501 kg
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Clutch: | hydraulic wet disc
|
| Rear RPM: | 540 (1.375)
|
| Electrical |
| Ground: | negative
|
| Charging system: | alternator
|
| Charging amps: | 40
|
| Battery CCA: | 582
|
| Battery volts: | 12
|
| Page information |
| Last update: | March 29, 2021
|
| Copyright: | Copyright 2021 TractorData LLC
|
| Contact: | Peter@TractorData.com
|
