Tractors > John Deere > 7520

John Deere 7520 - tests

John Deere 7520 tractor photo
2003 - 2007   7020 Series
Row-Crop tractor
Previous model:John Deere 7510
Next model:John Deere 7530 Premium
Series back:John Deere 7420
more John Deere 7520 specifications...






OCED Tractor Test 1818:

Nebraska summary:395
7520 fuel use from test 395
Test Date:March 25 - April 17, 2003
Type:Diesel IVT 4WD
PTO power (max):143.97 hp [107.4 kW]
PTO fuel use (max):7.6 gal/hour [28.8 l/hour]
PTO power (rated engine speed):125.75 hp [93.8 kW]
PTO fuel use (engine speed):6.7 gal/hour [25.4 l/hour]
Drawbar power (max):110.88 hp [82.7 kW]
Drawbar fuel use (max):7.4 gal/hour [28.0 l/hour]
Drawbar pull (max):13,634 lbs [6184 kg]
Max pull gear:4-kph
Test report:PDF file
