    John Deere 6420 - engine

    John Deere 6420 tractor photo
    2002 - 2006
    Utility tractor
    Previous model:John Deere 6410
    Next model:John Deere 6430
    Series back:John Deere 6320
    more John Deere 6420 specifications...






    Engine Detail:

     John Deere PowerTech 4045HL070
     turbocharged diesel
     4-cylinder
     liquid-cooled
     276 ci [4.5 L]
    Bore/Stroke:4.19x5.00 inches [106 x 127 mm]
    Emissions:Tier I
    Power:110 hp [82.0 kW]
    Air cleaner:dry
    Rated RPM:2300
    Idle RPM:875-2510
    Operating RPM:1000-2300
    Torque:273 lb-ft [370.2 Nm]
    Torque RPM:1500
    Firing order:1-3-4-2
    Starter volts:12
    Starter power:4 hp [3.0 kW]
    Oil capacity:16.8 qts [15.9 L]
    Oil change:500 h
    Coolant capacity:14.4 qts [13.6 L]
    Intake valve clearance:0.014 inches [0.356 mm]
    Exhaust valve clearance:0.018 inches [0.457 mm]


    Engine Detail:

    Used a Denso High-Pressure Common Rail (HPCR) fuel injection system. Also engine model 4045HL475
     John Deere PowerTech 4045HL473
     turbocharged diesel
     4-cylinder
     liquid-cooled
     276 ci [4.5 L]
    Bore/Stroke:4.19x5.00 inches [106 x 127 mm]
    Emissions:Tier II
    Power:110 hp [82.0 kW]
    Air cleaner:dry
    Rated RPM:2300
    Idle RPM:845-2465
    Torque:346 lb-ft [469.2 Nm]
    Torque RPM:1500
    Firing order:1-3-4-2
    Starter volts:12
    Starter power:4 hp [3.0 kW]
    Oil capacity:16.8 qts [15.9 L]
    Oil change:500 h
    Coolant capacity:14.4 qts [13.6 L]
    Intake valve clearance:0.014 inches [0.356 mm]
    Exhaust valve clearance:0.018 inches [0.457 mm]
