Tractors > John Deere > 6220

John Deere 6220 - engine

John Deere 6220 tractor photo
2002 - 2007
Utility tractor
Previous model:John Deere 6210
Series next:John Deere 6320
Series back:John Deere 6120
more John Deere 6220 specifications...






Engine Detail:

 John Deere PowerTech 4045TL071
 turbocharged diesel
 4-cylinder
 liquid-cooled
 276 ci [4.5 L]
Bore/Stroke:4.19x5.00 inches [106 x 127 mm]
Emissions:Tier I
Power:90 hp [67.1 kW]
Air cleaner:dry
Rated RPM:2300
Idle RPM:875-2510
Operating RPM:1000-2300
Torque:220 lb-ft [298.3 Nm]
Torque RPM:1500
Firing order:1-3-4-2
Starter volts:12
Starter power:4 hp [3.0 kW]
Oil capacity:16.8 qts [15.9 L]
Oil change:500 h
Coolant capacity:14.4 qts [13.6 L]
Intake valve clearance:0.014 inches [0.356 mm]
Exhaust valve clearance:0.018 inches [0.457 mm]


Engine Detail:

 John Deere PowerTech 4045TL272
 turbocharged diesel
 4-cylinder
 liquid-cooled
 276 ci [4.5 L]
Bore/Stroke:4.19x5.00 inches [106 x 127 mm]
Emissions:Tier II
Power:90 hp [67.1 kW]
Air cleaner:dry
Rated RPM:2300
Idle RPM:845-2465
Operating RPM:1000-2300
Torque:281 lb-ft [381.0 Nm]
Torque RPM:1500
Firing order:1-3-4-2
Oil capacity:16.8 qts [15.9 L]
Oil change:500 h
Coolant capacity:14.4 qts [13.6 L]
Intake valve clearance:0.014 inches [0.356 mm]
Exhaust valve clearance:0.018 inches [0.457 mm]
