John Deere 4520



John Deere 4520 tractor photo
2005 - 2014
Model year
4000 Twenty Compact Series
Compact Utility tractor
Series map:
4320
4520
4720
48.1hp
53.1hp
58.1hp
Production
ManufacturerJohn Deere
Compact Utility tractor
Built in Augusta, Georgia, USA
During Nebraska testing, the John Deere 4720 was unable to produce the advertised 12 GPM hydraulic flow rate, actual flow was 10.8 GPM.
John Deere 4520 Engine
John Deere 2.4L 4-cyl diesel
Engine details ...
John Deere 4520 Transmissions
12-speed
hydrostatic
Transmission details ...
John Deere 4520 Power
Engine53.1 hp
39.6 kW
PTO (claimed)40 hp
29.8 kW
PTO (tested)46.58 hp
34.7 kW
Performance test details ...
Mechanical
Four-wheel drive
Steeringhydrostatic power
Wet disc brakes
Cab optional with heat and air-conditioning.
Photos
John Deere 4520
John Deere 4520 photos...
Capacity
Fuel14.5 gal
54.9 L
 13.8 gal (with cab)
52.2 L
Hydraulic system10.3 gal
39.0 L
 9.6 gal (eHydro)
36.3 L
Hydraulics
Typeopen center
Capacity10.3 gal
39.0 L
 9.6 gal (eHydro)
36.3 L
Pressure2500 psi
172.4 bar
Valves0 to 5
Pump flow12 gpm
45.4 lpm
Total flow17.1 gpm
64.7 lpm
Steering flow5.1 gpm
19.3 lpm
Tractor hitch
Rear TypeI
Rear lift (at ends)3,130 lbs
1419 kg
Rear lift (at 24"/610mm)2,500 lbs
1134 kg
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540
Mid PTOindependent OptOptional
Mid PTO Type2100
Dimensions & Tires
Wheelbase71.5 inches
181 cm
Weight3855 to 4345 pounds
Front tire8.00-16
Rear tire13.6-28
Full dimensions and tires ...
John Deere 4520 attachments
72" mid-mount mower deck
front-end loader
backhoe
Attachment details ...
Electrical
Groundnegative
Charging systemalternator
Charging amps70
Battery CCA770
Battery volts12
References
4520 references literature
Commercial & Consumer Equipment Purchasing Guide published in 2007, by John Deere
Commercial & Consumer Equipment Purchase Guide published in 2005, by John Deere
