Kioti LB1914
|
|
| Production | |
| Manufacturer | Kioti (a part of Daedong) |
| Compact Utility tractor | |
| Built in Daegu, South Korea | |
| Original price was $11,000 in 2006 | |
| Kioti LB1914 Engine | |
| Daedong 0.9L 3-cyl diesel | |
| Fuel tank | 5.5 gal 20.8 L |
 Engine details ... | |
| Kioti LB1914 Transmission | |
| 8-speed synchronized shuttle | |
 Transmission details ... |
| Kioti LB1914 Power | |
| Engine (gross) | 19.5 hp 14.5 kW |
| PTO (claimed) | 17 hp 12.7 kW |
| Mechanical | |
| Four-wheel drive | |
| Steering | power |
| Wet disc brakes | |
| Two-post folding ROPS. Canopy optional. | |
| Photos | |
 | |
 Kioti LB1914 photos... | |
| Hydraulics | |
| Type | open center |
| Pump flow | 6 gpm 22.7 lpm |
| Tractor hitch | |
| Rear Type | I |
| Control | position control |
| Rear lift (at 24"/610mm) | 1460 lbs 662 kg |
| Power Take-off (PTO) | |
| Rear PTO | transmission |
| Clutch | overrunning |
| Rear PTO Type | 540/1000 (1.375) |
| Engine RPM | 540@2405 |
| 1000@2400 | |
| Front PTO Type | 2800 |
| Dimensions & Tires | |
| Wheelbase | 56 inches 142 cm |
| Weight | 2132 lbs 967 kg |
| Front tire | 6-12 |
| Rear tire | 9.5-20 |
 Full dimensions and tires ... | |
| Kioti LB1914 attachments | |
| front-end loader | |
| backhoe | |
 Attachment details ... |
| LB1914 Serial Numbers | |
| Location: | Serial number on the tractor's transmission housing ahead of the clutch pedal. |
| 1990 | 600001 |
| 1991 | 700001 |
| 1992 | 800001 |
| 1993 | 900001 |
FAQ: How to read a serial number table. | |
| Electrical | |
| Ground | negative |
| Battery volts | 12 |
| References | |
 | |
| The Leader of the Pack published in 1999, by Kitoi | |
| LB1914 - 4WD published by Kitoi |
