Versatile 1080 Big Roy


Versatile 1080 Big Roy tractor photo
1977
Experimental tractor
Production
Manufacturer:Versatile
Type:Experimental tractor
Factory:Winnipeg, Manitoba, Canada
Total built:1
The Versatile 1080 "Big Roy" was a prototype. The 26-ton tractor featured a four-axle 8x8 drive, and a 19-liter Cummins KTA 1150-600 diesel generating 600 horsepower. A camera system with in-cab monitors was used for the operator. The tractor is now at the Manitoba Agricultural Museum.
Versatile 1080 Power
Engine:600 hp
447.4 kW
Versatile 1080 Engine
Cummins 18.8L 6-cyl diesel
Fuel tank:550 gal
2081.8 L
Engine details ...
Mechanical
Chassis:8x8 8WD
Transmission:6-speed
Transmission details ...
Dimensions & Tires
Wheelbase:266.4 inches
676 cm
Weight:57,580 lbs
26118 kg
Front tire:30.5-32
Rear tire:30.5-32
Full dimensions and tires ...
Links
Big Roy: Information from the Manitoba Agricultural Museum
Big Roy 1080: Photo from Versatile-Tractors.com
Electrical
Ground:negative
Batteries:2
Battery CCA:900
Battery volts:12
