Versatile 1156
| | 1986 - 1991 |
| Four-wheel Drive (4WD) tractor |
|
| Production |
| Manufacturer: | Versatile
|
| Type: | Four-wheel Drive (4WD) tractor
|
| Factory: | Winnipeg, Manitoba, Canada
|
| Original price: | $171,000 (1991 )
|
| Versatile 1156 Power |
| Engine: | 470 hp
350.5 kW
|
| Mechanical |
| Chassis: | 4x4 articulated 4WD
|
| Steering: | hydrostatic power
|
| Brakes: | disc and caliper
|
| Cab: | Cab standard with air-conditioning and AM/FM stereo cassette radio.
|
| Transmission: | 8-speed
|
 Transmission details ... |
| Photos |
| No photos of the Versatile 1156 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Capacity |
| Fuel: | 400 gal
1514.0 L
|
| Hydraulic system: | 100 gal
378.5 L
|
| Hydraulics |
| Type: | closed center load-sensing
|
| Capacity: | 100 gal
378.5 L
|
| Pressure: | 2500 psi
172.4 bar
|
| Valves: | 5
|
| Pump flow: | 27.7 gpm
104.8 lpm
|
| Total flow: | 55 gpm
208.2 lpm
|
| Power Take-off (PTO) |
| Rear RPM: | 1000
|
| 1156 Serial Numbers |
| Location: | Serial number plate on the cab door post.
|
| 1986: | 1156 86 270301
|
| 1987: | 1156 87 ------
|
| 1988: | 1156 88 331116
|
| 1989: | 1156 89 ------
|
| 1990: | 1156 90 ------
|
| 1991: | 1156 91 D475128
|
| Final: | 1156 91 D475197
|
how to read serial numbers...
|
| Electrical |
| Ground: | negative
|
| Charging system: | alternator
|
| Charging amps: | 90
|
| Batteries: | 4
|
| Battery volts: | 12
|
| Page information |
| Last update: | March 5, 2018
|
| Copyright: | Copyright 2021 TractorData LLC
|
| Contact: | Peter@TractorData.com
|
