Kubota M7030


Kubota M7030 tractor photo
1986 - 1998
M30 Series
Utility tractor
Series map:
M6030
M7030
M8030
61.0hp
71.0hp
81.0hp
Production
ManufacturerKubota
Utility tractor
Variants
M7030F2WD
M7030DT4WD
M7030LPLow-profile
M7030SUshort wheelbase
Kubota M7030 Engine
Kubota 4.0L 4-cyl diesel
Engine details ...
Kubota M7030 Power
Engine71 hp
52.9 kW
Drawbar (claimed)58.5 hp
43.6 kW
PTO (claimed)68 hp
50.7 kW
Drawbar (tested)56.83 hp
42.4 kW
PTO (tested)68.87 hp
51.4 kW
Performance test details ...
Mechanical
Two- or four-wheel drive
Differential lockmechanical rear
Power steering
Differential mechanical wet disc brakes
Two-post ROPS.
Capacity
Fuel16.9 gal
64.0 L
2WD Hydraulic system13.2 gal
50.0 L
4WD Hydraulic system16.2 gal
61.3 L
Hydraulics
Typeopen center
2WD Capacity13.2 gal
50.0 L
4WD Capacity16.2 gal
61.3 L
Pressure2630 psi
181.3 bar
Valves1
Total flow11 gpm
41.6 lpm
Tractor hitch
Rear TypeII
Rear lift (at ends)4848 lbs
2199 kg
Rear lift (at 24"/610mm)4475 lbs
2029 kg
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540 (1.375)
Engine RPM540@2035
Dimensions & Tires
Wheelbase87.4 inches (2WD)
221 cm
 89 inches (4WD)
226 cm
SU Wheelbase83.4 inches
211 cm
Weight4982 to 6040 pounds
Front tire7.50-16
Rear tire16.9-30 (2WD)
Full dimensions and tires ...
Electrical
Ground145 (2WD)
 151 (4WD)
Battery volts12
References
M7030 references literature
Front Loaders published in 1988, by Kubota
Front Loaders B, L and M-Series published in 1994, by Kubota*
Product Catalog published in 1990, by Kubota
M30 Series - Utility/Agri/Low Profile published in 1986, by Kubota
M30 Series - Utility-Agri/Low Profile/Narrow/Mudder published in 1991, by Kubota
Low Profile Tractor M7030 4WD published in 1987, by Kubota
Utility Special Tractor M7030SU 2WD published in 1990, by Kubota
*Publication contains known errors.
