Kubota M4000
|
|
| Production | |
| Manufacturer | Kubota |
| Utility tractor | |
| Kubota M4000 Engine | |
| Kubota 2.2L 6-cyl diesel | |
| Fuel tank | 14.3 gal 54.1 L |
 Engine details ... | |
| Kubota M4000 Transmission | |
| 16-speed synchronized | |
 Transmission details ... |
| Kubota M4000 Power | |
| Engine | 47.5 hp 35.4 kW |
| PTO (claimed) | 40.9 hp 30.5 kW |
| Mechanical | |
| Two-wheel drive | |
| Power steering | |
| Wet disc brakes | |
| Open operator station. |
| Photos | |
 | |
 Kubota M4000 photos... | |
| Hydraulics | |
| Type | open center |
| Pressure | 2490 psi 171.7 bar |
| Valves | 1 |
| Pump flow | 7.3 gpm 27.6 lpm |
| Tractor hitch | |
| Rear Type | I |
| Control | position and draft control |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540/1000 (1.375) |
| Dimensions & Tires | |
| Wheelbase | 78.2 inches 198 cm |
| Weight | 4125 lbs 1871 kg |
| Front tire | 6.00-16 |
| Rear tire | 13.6-28 |
 Full dimensions and tires ... | |
| M4000 Serial Numbers | |
| Location: | Serial number on the left side of the tractor's clutch housing. |
| 1976 | 10061 |
| 1977 | 10361 |
| 1978 | 11071 |
| 1979 | 10124 |
| 1980 | 10164 |
| 1981 | 11204 |
| 1982 | 11244 |
| 1983 | 11284 |
FAQ: How to read a serial number table. | |
| Electrical | |
| Ground | negative |
| Battery volts | 12 |
| References | |
 | |
| M4000 published by Kubota |
