Tractors > Kubota > L225
      -Brand search:


    Kubota L225

    Kubota L225 tractor photo
    1974 - 1976
    Compact Utility tractor






    Production:

    Manufacturer:Kubota
    Factory:Japan
    Original price (USD):$4,500 (1976 L225DT)


    Variants:

    L225:2WD
    L225DT:4WD


    Kubota L225 Engine:

       Kubota 1.1L 3-cyl diesel
    full engine details ...


    Capacity:

    Front axle:0.9 qts [0.9 L]
    Front diff.:1.1 qts [1.0 L]


    3-Point Hitch:

    Rear Type:I


    Power Take-off (PTO):

    Rear RPMs:540/1000
    Engine RPMs:540@2534
    1000@2363


    Dimensions & Tires:

    Wheelbase:60.25 inches [153 cm]
    Weight:1995 to 3452 pounds
    Front tire:4.00-15
    Rear tire:9.5-24
    full dimensions and tires ...


    L225 Serial Numbers:


    - Serial numbers unknown -



    Kubota L225 Power:

    Engine:24 hp [17.9 kW]
    Drawbar (tested):16.06 hp [12.0 kW]
    PTO (tested):20.86 hp [15.6 kW]
    power test details ...


    Mechanical:

    Chassis:4x2 2WD
     4x4 MFWD 4WD (L225DT)
    Steering:manual
    Brakes:differential mechanical expanding shoe


    Hydraulics:

    Pressure:1700 psi [117.2 bar]
    Total flow:3.7 gpm [14.0 lpm]


    Electrical:

    Ground:negative


    Battery:

    Number:1
    Volts:12
