Kubota M8200 Transmission


Kubota M8200 tractor photo
1997 - 2005
M Series
Utility tractor
Series:M6800M8200M9000
Transmissions overview
8-speed synchronized
8-speed power shuttle
Transmission
Type:synchronized
Gears:8 forward and reverse
Clutch:299.7mm cerametallic dry disc
Oil capacity:54.8 qts
51.9 L
Speeds
M8200  synchronized speeds
Transmission
Type:power shuttle
Gears:8 forward and reverse
Clutch:hydraulic wet disc
Oil capacity:54.8 qts
51.9 L
The hydraulic power shuttle transmission became available in 2003. A creeper option was also available increasing speeds to 12/12.
Speeds
M8200  power shuttle speeds
