    CaseIH 1394

    No photo available
    1985 - 1988
    Previous model:J.I. Case 1394
    Larger:CaseIH 1494






    Production:

    Manufacturer:CaseIH
    Original price (USD):$22,000 (1988)


    CaseIH 1394 Engine:

       Case 3.6L 4-cyl diesel
    full engine details ...


    Capacity:

    Fuel:19 gal [71.9 L]
     26.4 gal [99.9 L] (with cab)


    3-Point Hitch:

    Rear Type:II/I
    Rear lift (at ends):5,000 lbs [2268 kg]
    Rear lift (at 24"/610mm):2,990 lbs [1356 kg]


    Power Take-off (PTO):

    Rear PTO:independent
    Rear RPMs:540/1000


    Dimensions & Tires:

    Wheelbase:83 inches [210 cm] (2WD)
     84.5 inches [214 cm] (4WD)
    Weight:6520 to 7160 pounds
    Front tire:7.50-16
    Rear tire:13.6-36
    full dimensions and tires ...


    1394 Serial Numbers:

    Location:Main frame on right side
    1985: 11502001
    1986: 11504635
    1987: 11506453
    1988: 11508682

    how to read serial numbers...



    CaseIH 1394 Power:

    Engine:77 hp [57.4 kW]
    PTO (claimed):65 hp [48.5 kW]


    Mechanical:

    Chassis:4x2 2WD
     4x4 MFWD 4WD (optional)
    Steering:hydrostatic power
    Brakes:drum
    Cab:Cab with air-conditioning optional.


    Hydraulics:

    Type:open center
    Pressure:2550 psi [175.8 bar]
    Valves:1 to 3
    Total flow:7.7 gpm [29.1 lpm]
     15.3 gpm [57.9 lpm] (tandem)
    Steering flow:7.7 gpm [29.1 lpm]
    Steering press.:1500 psi [103.4 bar]


    Electrical:

    Charging system:alternator
    Charging amps:45
     65 (heavy duty)


    Battery:

    Cold-cranking amps:420
     550 (heavy duty)
    Volts:12
    Amp-hours:96
     128 (heavy duty)
