    CaseIH 885

    CaseIH 885 tractor photo
    1985 - 1990   85 Utility Series
    Utility tractor
    Next model:CaseIH 895
    Larger:CaseIH 985






    Production:

    Manufacturer:CaseIH
    Factory:Doncaster, England
    Original price (USD):$25,700 (1990)


    CaseIH 885 Engine:

       Case International 4.4L 4-cyl diesel
    full engine details ...


    Capacity:

    Fuel:20 gal [75.7 L]
    Hydraulic system:9 gal [34.1 L]
     9.65 gal [36.5 L] (4WD)


    3-Point Hitch:

    Rear Type:II
    Rear lift (at 24"/610mm):3,260 lbs [1478 kg]


    Power Take-off (PTO):

    Rear PTO:independent dual shaft
    Rear RPMs:540/1000


    Dimensions & Tires:

    Wheelbase:88 inches [223 cm]
     85.2 inches [216 cm] (4WD)
    Weight:6065 to 7849 pounds
    Front tire:7.50-18
    Rear tire:18.4-30
    full dimensions and tires ...


    885 Serial Numbers:

    Location:Front-right of tractor
    1985: 15000
    1986: 18000
    1987: 19138
    1988: 22668
    1989: 27254
    1990: 30427

    how to read serial numbers...



    CaseIH 885 Power:

    Engine:79 hp [58.9 kW]
    PTO (claimed):72 hp [53.7 kW]


    Mechanical:

    Chassis:4x2 2WD
     4x4 MFWD 4WD (optional)
    Steering:hydrostatic power
    Brakes:independent hydraulic wet disc
    Cab:ROPS available. Cab with heat and A/C optional.


    Hydraulics:

    Type:open center gear pump
    Capacity:9 gal [34.1 L]
     9.65 gal [36.5 L] (4WD)
    Pressure:2500 psi [172.4 bar]
    Valves:1 to 3
    Pump flow:15.8 gpm [59.8 lpm]
    Total flow:15.8 gpm [59.8 lpm]
     18.6 gpm [70.4 lpm] (optional)
    Steering flow:2.5 gpm [9.5 lpm]


    Electrical:

    Charging system:Lucas alternator
    Charging amps:45 (ROPS)
     65 (cab)


    Battery:

    Number:1
    Volts:12
    Amp-hours:93
