    CaseIH 275 - transmission

    CaseIH 275 tractor photo
    Production years:1986 - 1991
    Previous model:International Harvester 284
    Tractor type:Farm/Agricultural tractor
    Smaller:CaseIH 255
    more CaseIH 275 specifications...






    Transmission:

    Type:synchromesh
    Forward:9
    Reverse:3
    Oil capacity:-unknown-
    Comments:Three gears in each of high, medium, low, and reverse ranges.
    Speeds:With 12.4-24 rear tires.

    Gear2700 rpm
    L11.23mph [2.0kph]
    L21.67mph [2.7kph]
    L32.25mph [3.6kph]
    M13.02mph [4.9kph]
    M24.11mph [6.6kph]
    M35.53mph [8.9kph]
    H16.91mph [11.1kph]
    H29.42mph [15.2kph]
    H312.66mph [20.4kph]
    R11.47mph [2.4kph]
    R23.61mph [5.8kph]
    R38.26mph [13.3kph]
