CaseIH C70 Tests


CaseIH C70 tractor photo
1998 - 2002
CX Utility Series
Utility tractor
Series:C60C70C80
OCED Tractor Test 1895
C70 fuel use from test 326
OCED Tractor Test 1895
Diesel 16-speed 4WD
October 1998 - November 1998,
Link: OCED Tractor Test 1895 file
PTO performance
Power at rated engine speed:59.7 hp
44.5 kW
Fuel use:3.9 gal/hour
14.8 l/hour
Power at rated PTO speed:62.1 hp
46.3 kW
Fuel use:3.9 gal/hour
14.8 l/hour
Drawbar performance
Max power:50.2 hp
37.4 kW
Fuel use:4.0 gal/hour
15.1 l/hour
Gear 3-Low-Direct used for power test.
Max pull:9,485 lbs
4302 kg
Gear 1-Low-TA used for pull test.
