Tractors > CaseIH > CX60
      -Brand search:

    CaseIH CX60

    CaseIH CX60 tractor photo
    1998 - 2002   CX Utility Series
    Utility tractor
    Previous model:CaseIH 3230
    Series next:CaseIH CX70
    Series back:CaseIH CX50



    Factory:Doncaster, England
    Original price (USD):$26,000 (1999)


    CX60:deluxe model
    C60:basic model

    CaseIH CX60 Engine:

       Perkins 2.7L 3-cyl diesel
    full engine details ...


    Fuel:42 gal [159.0 L]
    Hydraulic system:9.1 gal [34.4 L] (2WD)
     9.8 gal [37.1 L] (4WD)

    3-Point Hitch:

    Rear Type:II/I
    Control:electronic upper link
    Rear lift:3,665 lbs [1662 kg]
     5,097 lbs [2311 kg] (optional)

    Power Take-off (PTO):

    Rear PTO:independent
    Clutch:hydraulic wet disc
    Rear RPM:540
     540/1000 (optional dual shaft)

    Dimensions & Tires:

    Wheelbase:84.8 inches [215 cm] (2WD)
     87.2 inches [221 cm] (4WD)
    Weight:7286 to 7970 pounds
    Front tire:7.50-16
    Rear tire:14.9-28
    full dimensions and tires ...

    CX60 Serial Numbers:

    Location:Near the tractor steering column on right side.
    1998: JJE1000056
    1999: JJE1008492
    2000: JJE1013490
    2001: JJE1017672
    2002: JJE1019985

    how to read serial numbers...


    CaseIH CX60 Power:

    Engine (gross):64 hp [47.7 kW]
    Engine (net):60 hp [44.7 kW]
    PTO (claimed):50 hp [37.3 kW]
    Drawbar (tested):48.4 hp [36.1 kW]
    PTO (tested):56.5 hp [42.1 kW]
    power test details ...


    Chassis:4x2 2WD
     4x4 MFWD 4WD (optional)
    Differential lock:electro-hydraulic
    Steering:hydrostatic power
    Brakes:differential hydraulic wet disc
    Cab:Two-post ROPS with flat platform. Optional cab with air-conditioning.


    Type:open center
    Capacity:9.1 gal [34.4 L] (2WD)
     9.8 gal [37.1 L] (4WD)
    Pressure:2500 psi [172.4 bar]
    Valves:0 to 3
    Pump flow:13.7 gpm [51.9 lpm]
    Total flow:22.2 gpm [84.0 lpm] (total)
     13.7 gpm [51.9 lpm] (main pump)
     8.5 gpm [32.2 lpm] (lube pump)


    Charging system:alternator
    Charging amps:65


    Cold-cranking amps:650
     810 (optional)
