CaseIH CX60 Tests


CaseIH CX60 tractor photo
1998 - 2002
CX Utility Series
Utility tractor
Series map:
CX50
CX60
CX70
53.0hp
64.0hp
73.0hp
OCED Tractor Test 1894
CX60 fuel use from test 325
OCED Tractor Test 1894
Diesel 16-speed 4WD
April 1999 - August 1999,
Link: OCED Tractor Test 1894 file
PTO performance
Max power56.5 hp
42.1 kW
Fuel use3.4 gal/hour
12.9 l/hour
Power at rated engine speed56.2 hp
41.9 kW
Fuel use3.4 gal/hour
12.9 l/hour
Power at rated PTO speed55.0 hp
41.0 kW
Fuel use3.2 gal/hour
12.1 l/hour
Drawbar performance
Max power48.4 hp
36.1 kW
Fuel use3.4 gal/hour
12.9 l/hour
Gear 1_high-TA used for power test.
Max pull9,160 lbs
4154 kg
Gear 1-Low-Direct used for pull test.
