Tractors > Leyland > 802

Leyland 802

Leyland 802 tractor photo
1981 - 1982
Utility tractor






Production:

Manufacturer:Leyland
Original price (USD):$20,500 (1984)


Leyland 802 Engine:

   Leyland 3.8L 4-cyl diesel
full engine details ...


Capacity:



3-Point Hitch:

Rear Type:II
Control:position and draft control
Rear lift:5200 lbs [2358 kg]


Power Take-off (PTO):

Rear PTO:independent
Rear RPM:540


Dimensions & Tires:

Weight:6550 lbs [2971 kg]
Front tire:7.50x16
Rear tire:14.00x34
full dimensions and tires ...


802 Serial Numbers:


- Serial numbers unknown -



Leyland 802 Power:

Engine:82 hp [61.1 kW]
PTO (claimed):74 hp [55.2 kW]


Mechanical:

Chassis:4x2 2WD
Final drives:spur gear
Differential lock:mechanical rear
Steering:power
Brakes:hydraulic wet disc
Cab:Cab standard with heat.


Hydraulics:

Pressure:2600 psi [179.3 bar]
Pump flow:14.5 gpm [54.9 lpm]


Electrical:

Charging system:alternator
Charging amps:36


Battery:

Volts:12
