Leyland 802
|
|
| Production | |
| Manufacturer | Leyland |
| Utility tractor | |
| Original price | $20,500 (1984) |
| Variants | |
| 802 | 2WD |
| Leyland 802 Engine | |
| Leyland 3.8L 4-cyl diesel | |
 Engine details ... |
| Leyland 802 Transmission | |
| 9-speed synchromesh | |
 Transmission details ... |
| Leyland 802 Power | |
| Engine | 82 hp 61.1 kW |
| PTO (claimed) | 74 hp 55.2 kW |
| Mechanical | |
| Two-wheel drive | |
| Final drives | spur gear |
| Differential lock | mechanical rear |
| Power steering | |
| Hydraulic wet disc brakes | |
| Cab standard with heat. | |
| Photos | |
| No photos of the Leyland 802 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Pressure | 2600 psi 179.3 bar |
| Pump flow | 14.5 gpm 54.9 lpm |
| Tractor hitch | |
| Rear Type | II |
| Control | position and draft control |
| Rear lift | 5200 lbs 2358 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540 |
| Dimensions & Tires | |
| Weight | 6550 lbs 2971 kg |
| Front tire | 7.50x16 |
| Rear tire | 14.00x34 |
 Full dimensions and tires ... | |
| Electrical | |
| Charging system | alternator |
| Charging amps | 36 |
| Battery volts | 12 |
| References | |
 | |
| 802 - 804 published in 1981, by Leyland |
