    Steiger Panther CP-1360

    Steiger Panther CP-1360 tractor photo
    1982 - 1985   1000 Series
    Four-wheel Drive (4WD) tractor






    Production:

    Manufacturer:Steiger
    Factory:Fargo, North Dakota, USA
    Original price (USD)
       $136,000 (1985 )


    Variants:

    CP-1325:Caterpillar 325HP
    KP-1325:Cummins 325HP
    CP-1360:Caterpillar 360HP
    KP-1360:Cummins 360HP
    CP-1400:Caterpillar 400HP
    KP-1400:Cummins 400HP


    Steiger Panther CP-1360 Engine:

       Caterpillar 14.6L 6-cyl diesel
    full engine details ...


    Capacity:

    Fuel:230 gal [870.6 L]


    3-Point Hitch:

    Rear Type:III/IV


    Power Take-off (PTO):

    Rear PTO:independent
    Rear RPM:1000


    Dimensions & Tires:

    Wheelbase:141.5 inches [359 cm]
    Weight:35,300 lbs [16012 kg]
    Front tire:23.1-34
    Rear tire:23.1-34
    full dimensions and tires ...


    Panther CP-1360 Serial Numbers:

    1982: P07-00501
    1983: P07-02501
    1984: P07-03001
    1985: P07-05001

    how to read serial numbers...



    Steiger Panther CP-1360 Power:

    Engine:360 hp [268.5 kW]
    Drawbar (tested):289.91 hp [216.2 kW]
    PTO (tested):334.33 hp [249.3 kW]
    power test details ...


    Mechanical:

    Chassis:4x4 articulated 4WD
    Final drives:outboard planetary
    Steering:articulated power
    Brakes:hydraulic disc
    Cab:Cab standard with air-conditioning.


    Hydraulics:

    Type:closed center
    Valves:3


    Electrical:

    Ground:negative
    Charging system:alternator


    Battery:

    Volts:12
