Steiger Panther KP-1325


Steiger Panther KP-1325 tractor photo
1982 - 1985
1000 Series
Four-wheel Drive (4WD) tractor
Production
Manufacturer:Steiger
Type:Four-wheel Drive (4WD) tractor
Factory:Fargo, North Dakota, USA
Original price:$125,000 (1985 )
Variants
CP-1325:Caterpillar 325HP
KP-1325:Cummins 325HP
CP-1360:Caterpillar 360HP
KP-1360:Cummins 360HP
CP-1400:Caterpillar 400HP
KP-1400:Cummins 400HP
Steiger Panther KP-1325 Power
Engine:325 hp
242.4 kW
Drawbar (tested):264.44 hp
197.2 kW
PTO (tested):301.21 hp
224.6 kW
power test details ...
Steiger Panther KP-1325 Engine
Cummins 14.0L 6-cyl diesel
Fuel tank:230 gal
870.6 L
Engine details ...
Mechanical
Chassis:4x4 articulated 4WD
Final drives:outboard planetary
Steering:articulated power
Brakes:hydraulic disc
Cab:Cab standard with air-conditioning.
Transmission:12-speed full power shift
Transmission details ...
Hydraulics
Type:closed center
Valves:3
Tractor hitch
Rear Type:III/IV
Power Take-off (PTO)
Rear PTO:independent
Rear RPM:1000
Dimensions & Tires
Wheelbase:141.5 inches
359 cm
Weight:35300 lbs
16012 kg
Front tire:23.1-34
Rear tire:23.1-34
Full dimensions and tires ...
Panther KP-1325 Serial Numbers
1982:P04-00501
1983:P04-02501
1984:P05-03001
1985:P04-05001

how to read serial numbers...
