Steiger Cougar KR-1225


Steiger Cougar KR-1225 tractor photo
1985
1000 Series
Four-wheel Drive (4WD) tractor
Production
Manufacturer:Steiger
Type:Four-wheel Drive (4WD) tractor
Factory:Fargo, North Dakota, USA
Original price:$80,000 (1985)
Variants
CR1225:Caterpillar 225 HP
KR1225:Cummin 225 HP
CR1280:Caterpillar 280 HP
KR1280:Cummins 280 HP
Steiger Cougar KR-1225 Power
Engine:225 hp
167.8 kW
PTO (claimed):190 hp
141.7 kW
Mechanical
Chassis:4x4 articulated 4WD
Steering:articulated power
Brakes:hydraulic disc
Cab:Cab standard
Transmission:20-speed two-speed power shift
Transmission details ...
Hydraulics
Type:closed-center load sensing
Valves:3
Pump flow:30 gpm
113.6 lpm
Power Take-off (PTO)
Rear PTO:independent
Rear RPM:1000
Engine RPM:1000@2100
Dimensions & Tires
Weight:24,800 lbs
11249 kg
Front tire:18.4-38
Rear tire:18.4-38
Full dimensions and tires ...
Electrical
Charging system:alternator
