Steiger Panther IV CM-360


No photo available
1983 - 1985
IV Series
Four-wheel Drive (4WD) tractor
Production
Manufacturer:Steiger
Type:Four-wheel Drive (4WD) tractor
Factory:Fargo, North Dakota, USA
Variants
CM360:Caterpillar engine
KM360:Cummins engine
Steiger Panther IV CM-360 Power
Engine:360 hp
268.5 kW
Drawbar (claimed):301 hp
224.5 kW
Steiger Panther IV CM-360 Engine
Caterpillar 14.6L 6-cyl diesel
Fuel tank:267 gal
1010.6 L
Engine details ...
Mechanical
Chassis:4x4 articulated 4WD
Steering:articulated power
Brakes:hydraulic disc
Cab:Steiger Safari Cab standard with air-conditioning.
Transmission:20-speed Constant mesh 10-speed transmission with 2-speed transfer case.
Transmission details ...
Photos
No photos of the Steiger Panther IV CM-360 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Type:open center load sensing
Pressure:2250 psi
155.1 bar
Valves:3 to 5
Pump flow:31 gpm
117.3 lpm
Tractor hitch
Rear Type:III*Optional
Dimensions & Tires
Wheelbase:129 inches
327 cm
Weight:26903 lbs
12203 kg
Front tire:23.1x34
Rear tire:23.1x34
Full dimensions and tires ...
Electrical
Charging system:alternator
Charging amps:90
Batteries:3
Battery volts:12
