Steiger Cougar III PTA-280


Steiger Cougar III PTA-280 tractor photo
1981 - 1983
III Series
Four-wheel Drive (4WD) tractor
Production
Manufacturer:Steiger
Type:Four-wheel Drive (4WD) tractor
Factory:Fargo, North Dakota, USA
Original price:$103,000 (1983 )
Steiger Cougar III PTA-280 Power
Engine:280 hp
208.8 kW
Drawbar (claimed):225 hp
167.8 kW
PTO (claimed):125 hp
93.2 kW
Steiger Cougar III PTA-280 Engines
Cummins 14.0L 6-cyl diesel
Caterpillar 14.6L 6-cyl diesel
Fuel tank:225 gal
851.6 L
Engine details ...
Mechanical
Chassis:4x4 articualted 4WD
Final drives:outboard planetary
Steering:articulated power
Brakes:hydraulic disc
Cab:Safari Cab standard with air-conditioning.
Transmission:10-speed power shift with torque converter
Transmission details ...
Photos
No photos of the Steiger Cougar III PTA-280 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Type:open center
Pressure:2250 psi
155.1 bar
Valves:3 to 5
Pump flow:28.6 gpm
108.3 lpm
Tractor hitch
Rear Type:III*Optional
Power Take-off (PTO)
Rear PTO:independent
Rear RPM:540/1000
Dimensions & Tires
Wheelbase:132.5 inches
336 cm
Weight:27600 lbs
12519 kg
Front tire:23.1x34
Rear tire:23.1x34
Full dimensions and tires ...
Electrical
Charging system:alternator
Charging amps:90
