    Steiger Panther III ST-325

    Steiger Panther III ST-325 tractor photo
    1976 - 1983   III Series
    Four-wheel Drive (4WD) tractor






    Production:

    Manufacturer:Steiger
    Factory:Fargo, North Dakota, USA
    Original price (USD):$103,000 (1983)


    Steiger Panther III ST-325 Engine:

       Caterpillar 14.6L 6-cyl diesel
    full engine details ...


    Capacity:

    Fuel:267 gal [1010.6 L]


    3-Point Hitch:

    Rear Type:3


    Dimensions & Tires:

    Wheelbase:128 inches [325 cm]
    Weight:26,900 lbs [12201 kg]
    Front tire:23.1-34
    Rear tire:23.1-34
    full dimensions and tires ...


    Panther III ST-325 Serial Numbers:

    1976: 123-00001
    1977: 123-00123
    1978: 123-00370
    1979: 123-00627
    1980: 123-00887
    1981: 123-01124
    1982: 123-01501
    1983: 123-02501

    how to read serial numbers...



    Steiger Panther III ST-325 Power:

    Engine:325 hp [242.4 kW]
    Drawbar (tested):269.86 hp [201.2 kW]
    power test details ...


    Mechanical:

    Chassis:4x4 articulated 4WD
    Final drives:outboard planetary
    Steering:hydrostatic power
    Brakes:hydraulic disc
    Cab:Safari Cab standard with heat and air-conditioning.


    Hydraulics:

    Type:open center
    Pressure:2250 psi [155.1 bar]
    Valves:3 to 5
    Pump flow:31.9 gpm [120.7 lpm]


    Electrical:

    Ground:negative
    Charging system:alternator
    Charging amps:90


    Battery:

    Number:2
    Volts:12
    Amp-hours:208
    Group:8D
