Steiger Bearcat III ST-225


Steiger Bearcat III ST-225 tractor photo
1980 - 1983
III Series
Four-wheel Drive (4WD) tractor
Production
Manufacturer:Steiger
Type:Four-wheel Drive (4WD) tractor
Factory:Fargo, North Dakota, USA
Original price:$66,000 (1983 )
Variants
ST-225:fixed axle
PT-225:row-crop axle
Steiger Bearcat III ST-225 Power
Engine:225 hp
167.8 kW
Drawbar (tested):184.69 hp
137.7 kW
PTO (tested):105.69 hp
78.8 kW
power test details ...
Steiger Bearcat III ST-225 Engine
Caterpillar 10.5L 6-cyl diesel
Fuel tank:267 gal
1010.6 L
Engine details ...
Mechanical
Chassis:4x4 articulated 4WD
Final drives:outboard planetary
Steering:hydrostatic power
Brakes:hydraulic dry disc
Cab:Safari Cab standard with heat and air-conditioning.
Transmission:20-speed
Transmission details ...
Hydraulics
Type:open center
Pressure:2250 psi
155.1 bar
Valves:3 to 5
Pump flow:30.8 gpm
116.6 lpm
Tractor hitch
Rear Type:3*Optional
Dimensions & Tires
Wheelbase:128 inches
325 cm
Weight:25000 lbs
11340 kg
Front tire:23.1-34
Rear tire:23.1-34
Full dimensions and tires ...
Bearcat III ST-225 Serial Numbers
1980:109-00001
1981:109-00170
1982:109-01501
1983:109-02501

how to read serial numbers...

Electrical
Ground:negative
Charging system:alternator
Charging amps:90
Battery volts:12
