Minneapolis-Moline G706 Tests
|
|
| Nebraska Tractor Test 833 | |||
| |||
| Nebraska Tractor Test 833 | |
| Diesel 5-speed 4WD April 6 - 17, 1963 Link: Nebraska Tractor Test 833 file | |
| PTO performance | |
| Power at rated engine speed | 101.68 hp 75.8 kW |
| Fuel use | 7.5 gal/hour 28.4 l/hour |
| Power at rated PTO speed | 81.68 hp 60.9 kW |
| Fuel use | 5.9 gal/hour 22.3 l/hour |
| Drawbar performance | |
| Max power | 87.83 hp 65.5 kW |
| Fuel use | 7.4 gal/hour 28.0 l/hour |
| Gear 3 used for power test. | |
| Max pull | 11,491 lbs 5212 kg |
| Gear 1 used for pull test. | |
| Nebraska Tractor Test 834 | |||
| |||
| Nebraska Tractor Test 834 | |
| LP-gas 5-speed 4WD April 8 - 23, 1963 Link: Nebraska Tractor Test 834 file | |
| PTO performance | |
| Power at rated engine speed | 101.44 hp 75.6 kW |
| Fuel use | 11.4 gal/hour 43.1 l/hour |
| Power at rated PTO speed | 82.29 hp 61.4 kW |
| Fuel use | 8.9 gal/hour 33.7 l/hour |
| Drawbar performance | |
| Max power | 86.24 hp 64.3 kW |
| Fuel use | 11.0 gal/hour 41.6 l/hour |
| Gear 3 used for power test. | |
| Max pull | 11,293 lbs 5122 kg |
| Gear 1 used for pull test. | |
