Massey Ferguson 8220


Massey Ferguson 8220 tractor photo
1999 - 2003
8200 Series
Row-Crop tractor
Series map:
8220
8240
150.0hp*
161.1hp*
*Estimated engine power for comparison only.
Production
ManufacturerMassey Ferguson
Row-Crop tractor
Built in France
Original price$75,300
Massey Ferguson 8220 Transmissions
32-speed four-range power shift
18-speed full power shift
Transmission details ...
Massey Ferguson 8220 Power
PTO (claimed)135 hp
100.7 kW
Drawbar (tested)133.6 hp
99.6 kW
PTO (tested)135.4 hp
101.0 kW
Performance test details ...
Mechanical
Drive4x2 2WD
 4x4 MFWD 4WD (optional)
Steeringhydrostatic power
Independent hydraulic wet disc brakes
Cab standard
Capacity
Fuel103 gal
389.9 L
Hydraulic system35 gal
132.5 L
Hydraulics
Typepressure flow compensated (PFC)
Capacity35 gal
132.5 L
Valves3
Pump flow27.7 gpm
104.8 lpm
Tractor hitch
Rear TypeIII
Rear lift14000 lbs
6350 kg
Power Take-off (PTO)
Rear PTOindependent
Rear RPM540,1000
Dimensions & Tires
Wheelbase108 inches
274 cm
Weight14760 to 15895 pounds
Front tire11.00-16
Rear tire18.4R-38
Full dimensions and tires ...
Electrical
Groundnegative
Battery volts12
