Massey Ferguson 4235
|
|
| Production | |
| Manufacturer: | Massey Ferguson |
| Type: | Utility tractor |
| Factory: | Coventry, England |
| Original price: | $34,000 (1999 ) |
| Massey Ferguson 4235 Power | |
| Engine (net): | 75 hp 55.9 kW |
| PTO (claimed): | 65 hp 48.5 kW |
| Drawbar (tested): | 51.6 hp 38.5 kW |
| PTO (tested): | 65.4 hp 48.8 kW |
| Massey Ferguson 4235 Engine | |
| Perkins 4.2L 4-cyl diesel | |
 Engine details ... |
| Mechanical | |
| Chassis: | 4x2 2WD |
| 4x4 MFWD 4WD | |
| Final drives: | outboard planetary |
| Steering: | hydrostatic power |
| Brakes: | independent hydraulic wet disc |
| Cab: | Two-post foldable ROPS. Cab optional with air-conditioning. |
| Transmissions: | 12-speed power shuttle |
| 18-speed two-speed power shift | |
 Transmission details ... | |
| Photos | |
| No photos of the Massey Ferguson 4235 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Capacity | |
| Fuel: | 33.6 gal 127.2 L (cab) |
| 34.3 gal 129.8 L (ROPS) | |
| 29.1 gal 110.1 L (Hi-Vis ROPS) | |
| 16.4 gal 62.1 L (cab opt.) | |
| 18.5 gal 70.0 L (ROPS opt.) | |
| Hydraulic system: | 13.2 gal 50.0 L |
| Hydraulics | |
| Type: | open center |
| Capacity: | 13.2 gal 50.0 L |
| Pressure: | 3046 psi 210.0 bar |
| Valves: | 2 to 4 |
| Pump flow: | 17.4 gpm 65.9 lpm |
| Tractor hitch | |
| Rear Type: | II |
| Control: | position and draft control |
| Rear lift (at ends): | 4339 lbs 1968 kg |
| 5260 lbs 2385 kg (optional) | |
| Power Take-off (PTO) | |
| Rear PTO: | independent |
| Clutch: | hydraulic wet disc |
| Rear RPM: | 540/1000 (1.375) |
| Dimensions & Tires | |
| Wheelbase: | 93 inches 236 cm |
| Weight: | 6753 to 8185 pounds |
| Front tire: | 7.5L-15 |
| Rear tire: | 16.9-30 |
 Full dimensions and tires ... | |
| Massey Ferguson 4235 attachments | |
| front-end loader | |
 Attachment details ... |
| 4235 Serial Numbers | |
| 1997: | F01001 |
| 1998: | G01001 |
| 1999: | H01001 |
| Electrical | |
| Ground: | negative |
| Charging system: | alternator |
| Charging amps: | 45 (ROPS) |
| 70 (Cab) | |
| Batteries: | 2 |
| Battery CCA: | 590 |
| Battery volts: | 12 |
