Massey Ferguson 4233
|
|
| Production | |
| Manufacturer | Massey Ferguson |
| Utility tractor | |
| Built in Coventry, England | |
| Original price was $28,000 in 1999 | |
| Massey Ferguson 4233 Engine | |
| Perkins 4.2L 4-cyl diesel | |
 Engine details ... |
| Massey Ferguson 4233 Transmissions | |
| 8-speed nonsynchronized gear | |
| 12-speed partially synchronized | |
| 8-speed synchronized shuttle | |
| 12-speed synchronized shuttle | |
 Transmission details ... |
| Massey Ferguson 4233 Power | |
| Engine (net) | 75 hp 55.9 kW |
| PTO (claimed) | 65 hp 48.5 kW |
| Drawbar (tested) | 60.2 hp 44.9 kW |
| PTO (tested) | 68.5 hp 51.1 kW |
 Performance test details ... | |
| Mechanical | |
| Two- or four-wheel drive | |
| Steering | hydrostatic power |
| Independent hydraulic wet disc brakes | |
| Two-post foldable ROPS. Cab optional with air-conditioning. | |
| Photos | |
| No photos of the Massey Ferguson 4233 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Capacity | |
| Fuel | 33.6 gal (cab) 127.2 L |
| 34.3 gal (ROPS) 129.8 L | |
| 29.1 gal (Hi-Vis) 110.1 L | |
| 16.4 gal (cab opt.) 62.1 L | |
| 18.5 gal (ROPS opt.) 70.0 L | |
| Hydraulic system | 13.2 gal 50.0 L |
| Hydraulics | |
| Type | open center |
| Capacity | 13.2 gal 50.0 L |
| Pressure | 3046 psi 210.0 bar |
| Valves | 2 to 4 |
| Pump flow | 10 gpm 37.9 lpm |
| 14 gpm (combined) 53.0 lpm | |
| 17.4 gpm (combined opt.) 65.9 lpm | |
| Tractor hitch | |
| Rear Type | II |
| Control | position and draft control |
| Rear lift (at ends) | 4339 lbs 1968 kg |
| 4984 lbs (optional) 2260 kg | |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Clutch | hydraulic wet disc |
| Rear PTO Type | 540 (1.375) |
| 540/1000 (1.375) | |
| Dimensions & Tires | |
| Wheelbase | 93 inches 236 cm |
| Weight | 6753 to 8170 pounds |
| Front tire | 7.5L-15 |
| Rear tire | 16.9-30 |
 Full dimensions and tires ... | |
| Massey Ferguson 4233 attachments | |
| front-end loader | |
 Attachment details ... |
| 4233 Serial Numbers | |
| 1997 | F01001 |
| 1998 | G01001 |
| 1999 | H01001 |
FAQ: How to read a serial number table. | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 45 (ROPS) |
| 70 (Cab) | |
| Batteries | 2 |
| Battery CCA | 590 |
| Battery volts | 12 |
| References | |
 | |
| MF Loaders for Compact & Agricultural Tractors published in 2003, by Massey Ferguson | |
| MF 4200 Series published in 2000, by Massey Ferguson |
