     World-Wide Guide to Massey Ferguson Tractors
    World-Wide Guide to Massey Ferguson Tractors

    Massey Ferguson 3525

    Massey Ferguson 3525 tractor photo  I&T Manual: Massey 3505, 3525, 3545
    I&T Shop Manual
    1983 - 1987
    Larger:Massey Ferguson 3545
    Smaller:Massey Ferguson 3505



    Manufacturer:Massey Ferguson
    Original price (USD):$42,100 (1987)

    Massey Ferguson 3525 Engine:

       Perkins 5.8L 6-cyl diesel
    full engine details ...



    3-Point Hitch:

    Rear Type:II
    Rear lift (at 24"/610mm):7,611 lbs [3452 kg]

    Power Take-off (PTO):

    Rear PTO:independent
    Rear RPMs:540/1000

    Dimensions & Tires:

    Wheelbase:107 inches [271 cm]
    Weight:13100 to 14645 pounds
    Front tire:10.00-16
    Rear tire:18.4-38
    full dimensions and tires ...

    3525 Serial Numbers:

    Location:Instrument panel on right
    1983: K241213
    1984: T101201
    1985: L101201
    1986: U031201
    1987: V001201

    how to read serial numbers...


    Massey Ferguson 3525 Power:

    PTO (claimed):105 hp [78.3 kW]
    Drawbar (tested):90.10 hp [67.2 kW]
    PTO (tested):108.01 hp [80.5 kW]
    power test details ...


    Chassis:4x2 2WD
     4x4 MFWD 4WD (optional)
    Differential lock:hydraulic
    Steering:hydrostatic power
    Brakes:differential hydraulic wet disc
    Cab:Cab standard with air-conditioning. Optional four-post ROPS canopy.


    Type:open center
    Pressure:2539 psi [175.1 bar]
    Valves:2 or 3
    Pump flow:15 gpm [56.8 lpm]
    Total flow:29.5 gpm [111.7 lpm] (total)
     14.5 gpm [54.9 lpm] (main pump)
     15 gpm [56.8 lpm] (two-spool aux pump)
