    Massey Ferguson 690

    Massey Ferguson 690 tractor photo
    1983 - 1986   600 Series
    Next model:Massey Ferguson 3060
    Larger:Massey Ferguson 690T
    Smaller:Massey Ferguson 670






    Production:

    Manufacturer:Massey Ferguson
    Factory:Beauvais, France
    Original price (USD):$29,000 (1986)


    Variants:

    690:naturally-aspirated
    690T:turbocharged


    Massey Ferguson 690 Engine:

       Perkins 4.1L 4-cyl diesel
    full engine details ...


    Capacity:



    3-Point Hitch:

    Rear Type:II
    Rear lift:4130 lbs [1873 kg]


    Power Take-off (PTO):

    Rear PTO:independent
    Rear RPM:540/1000


    Dimensions & Tires:

    Wheelbase:90 inches [228 cm]
    Weight:8020 to 10295 pounds
    Front tire:10.00-16
    Rear tire:16.9-34
    full dimensions and tires ...


    690 Serial Numbers:

    Location:On bottom left of instrument panel.
    1983: B197022
    1983: K181026
    1984: T101001
    1985: L101001
    1986: U031001

    how to read serial numbers...



    Massey Ferguson 690 Power:

    Engine:80 hp [59.7 kW]
    PTO (claimed):65 hp [48.5 kW]
    Drawbar (tested):52.38 hp [39.1 kW]
    PTO (tested):65.68 hp [49.0 kW]
    power test details ...


    Mechanical:

    Chassis:4x2 2WD
     4x4 MFWD 4WD
    Steering:hydrostatic power
    Brakes:differential hydraulic wet disc
    Cab:Cab standard.


    Hydraulics:

    Type:open center
    Valves:2
    Total flow:17 gpm [64.3 lpm]


    Battery:
