Massey Ferguson 670

Massey Ferguson 670 tractor photo
1983 - 1986   600 Series
Utility tractor
Next model:Massey Ferguson 3050
Series next:Massey Ferguson 690






Production:

Manufacturer:Massey Ferguson
Factory:Beauvais, France
Original price (USD):$26,000 (1986)


Massey Ferguson 670 Engine:

   Perkins 3.9L 4-cyl diesel
full engine details ...


Capacity:



3-Point Hitch:

Rear Type:II
Control:position and draft control
Rear lift (at 24"/610mm):4440 lbs [2013 kg]


Power Take-off (PTO):

Rear PTO:independent
Rear RPM:540/1000


Dimensions & Tires:

Wheelbase:90 inches [228 cm]
Weight:8720 to 9200 pounds
Front tire:7.50x16
2WD Rear tire:15.5x38
full dimensions and tires ...


670 Serial Numbers:


- Serial numbers unknown -



Massey Ferguson 670 Power:

Drawbar (claimed):46 hp [34.3 kW]
PTO (claimed):56 hp [41.8 kW]
Drawbar (tested):46.28 hp [34.5 kW]
PTO (tested):55.62 hp [41.5 kW]
power test details ...


Mechanical:

Chassis:4x2 2WD
 4x4 MFWD 4WD
Final drives:outboard planetary
Differential lock:mechanical rear
Steering:power
Brakes:hydraulic wet disc
Cab:Cab standard with available air-conditioning.


Hydraulics:

Type:open center
Valves:2
Total flow:17 gpm [64.3 lpm]


Electrical:

Ground:negative
Charging system:alternator


Battery:

Volts:12
