Massey Ferguson 285
| | 1974 - 1982 |
| 200 Series | | Row-Crop tractor |
|
Series map:
275
285
74.4hp*
90.0hp*
*Estimated engine power for comparison only.
| Production |
| Manufacturer | Massey Ferguson
|
| Row-Crop tractor |
| Built in Detroit, Michigan, USA |
| Original price was $24,500 in 1982 |
| Massey Ferguson 285 Power |
| PTO (claimed) | 81 hp
60.4 kW
|
| Drawbar (tested) | 69.46 hp
51.8 kW
|
| PTO (tested) | 81.96 hp
61.1 kW
|
 Performance test details ... |
| Mechanical |
| Two- or four-wheel drive |
| Differential lock | mechanical rear
|
| Power steering |
| Wet disc brakes |
| Two-post ROPS standard. Cabin and open operator station available. |
| Capacity |
| Fuel | 23 gal
87.1 L
|
| Hydraulic system | 8.5 gal
32.2 L
|
| Hydraulics |
| Capacity | 8.5 gal
32.2 L
|
| Pressure | 2300 psi
158.6 bar
|
| Valves | 1 to 3
|
| Pump flow | 7 gpm*Hitch
26.5 lpm
|
| | 10 gpm*Remote hydraulics
37.9 lpm
|
| Steering flow | 5.6 gpm
21.2 lpm
|
| Tractor hitch |
| Rear Type | II
|
| Rear lift | 4400 lbs
1995 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Rear PTO Type | 540 (1.375)
|
| | 1000 (1.375)
|
| Engine RPM | 540@1730
|
| | 1000@2000
|
| 285 Serial Numbers |
| Location: | Below instrument panel
|
| 1974 | 9A202190
|
| 1975 | 9A207681
|
| 1976 | 9A232539
|
| 1977 | 9A254045
|
| 1978 | 9A276935
|
| 1979 | 9A296946
|
| 1980 | 9A326169
|
| 1981 | 9A339343
|
| 1982 | 9A344679
|
| 1983 | 9A350584
|
FAQ: How to read a serial number table.
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Battery volts | 12
|
| References |
 |
| Loaders and Spreaders published in 1979, by Massey Ferguson |
| MF 34-81HP Tractors published in 1980, by Massey Ferguson |
| MF 200 Series Tractors published in 1982, by Massey Ferguson |
| MF 285/1085 Tractors published in 1976, by Massey Ferguson |
| 285 published in 1976, by Massey Ferguson |
| MF285 Cab Tractor published in 1981, by Massey Ferguson |
| Complete Farm Machinery Guide published in 1976, by Massey Ferguson |
