Massey Ferguson 85 Engine
|
|
| Engines overview | |
| Continential 3.7L 4-cyl gasoline | |
| Continential 4.0L 4-cyl gasoline | |
| Continental 4.0L 4-cyl LP gas | |
| Continential 4.5L 4-cyl diesel |
| Engine Detail | |
| Continential E-223 | |
| gasoline | |
| 4-cylinder | |
| liquid-cooled vertical L-head | |
| The E223 was used on early-production models of the Massey 85. It was replaced with the E242. | |
| Displacement | 223 ci 3.7 L |
| Bore/Stroke | 3.8125x5.125 inches 97 x 130 mm |
| Air cleaner | oil bath |
| Compression | 7.35:1 |
| Rated RPM | 2000 |
| Starter volts | 12 |
| Oil capacity | 7 qts 6.6 L |
| Coolant capacity | 15 qts 14.2 L |
| Massey Ferguson 85 Engine | |
 |
| Engine Detail | |
| Continential E-242 | |
| gasoline | |
| 4-cylinder | |
| liquid-cooled vertical L-head | |
| Late engine. The 242 replaced the earlier Continental 223. | |
| Displacement | 242 ci 4.0 L |
| Bore/Stroke | 3.875x5.125 inches 98 x 130 mm |
| Air cleaner | oil bath |
| Compression | 7.35:1 |
| Rated RPM | 2000 |
| Engine Detail | |
| Continental E-242 | |
| LP gas | |
| 4-cylinder | |
| liquid-cooled vertical L-head | |
| Displacement | 242 ci 4.0 L |
| Bore/Stroke | 3.875x5.125 inches 98 x 130 mm |
| Compression | 8.8:1 |
| Rated RPM | 2000 |
| Engine Detail | |
| Continential | |
| diesel | |
| 4-cylinder | |
| liquid-cooled | |
| Displacement | 276.5 ci 4.5 L |
| Bore/Stroke | 4.00x5.50 inches 102 x 140 mm |
| Air cleaner | oil bath |
| Compression | 15.2:1 |
| Rated RPM | 2000 |
