| | Engine Detail: |
| | Continential
|
| | gasoline
|
| | 4-cylinder
|
| | liquid-cooled vertical I-head
|
| | 176 ci [2.9 L]
|
|
|
|
| Bore/Stroke: | 3.578x4.375 inches [91 x 111 mm]
|
| Compression: | 7.1:1
|
| Rated RPMs: | 2000
|
| Starter volts: | 12
|
| Coolant capacity: | 10.4 qts [9.8 L]
|
| |
Engine Detail: |
| | Perkins 4A-203
|
| | diesel
|
| | 4-cylinder
|
| | liquid-cooled vertical L-head
|
| | 203.5 ci [3.3 L]
|
| Bore/Stroke: | 3.60x5.00 inches [91 x 127 mm]
|
| Air cleaner: | oil bath
|
| Compression: | 17.4:1
|
| Rated RPMs: | 2000
|
| Starter volts: | 12
|
| Oil capacity: | 7.5 qts [7.1 L]
|
| Coolant capacity: | 40 qts [37.9 L]
|
| Intake valve clearance: | 0.010 inches [0.254 mm]
|
| Exhaust valve clearance: | 0.010 inches [0.254 mm]
|
|
| |
Engine Detail: |
| | Perkins A4.192
|
| | diesel
|
| | 4-cylinder
|
| | liquid-cooled
|
| | 192 ci [3.1 L]
|
| Bore/Stroke: | 3.50x5.00 inches [89 x 127 mm]
|
| Air cleaner: | oil bath
|
| Compression: | 16.5:1
|
| Rated RPMs: | 2000
|
| Firing order: | 1-3-4-2
|
| Oil capacity: | 6.31 qts [6.0 L]
|
| Coolant capacity: | 9 qts [8.5 L]
|
| Intake valve clearance: | 0.012 inches [0.305 mm] (cold)
|
| Exhaust valve clearance: | 0.012 inches [0.305 mm] (cold)
|
 |
| |
| |
Engine Detail: |
| | Continental
|
| | LP gas
|
| | 4-cylinder
|
| | liquid-cooled
|
| | 176 ci [2.9 L]
|
| Bore/Stroke: | 3.578x4.375 inches [91 x 111 mm]
|
| Compression: | 8:1
|
| Rated RPMs: | 2000
|
| |
