Massey-Harris 44 Row-Crop
| | 1947 - 1953 |
| Row-Crop tractor |
|
| Production |
| Manufacturer: | Massey-Harris
|
| Type: | Row-Crop tractor
|
| Factory: | Racine, Wisconsin, USA
|
| Total built: | 84,000
|
| Massey-Harris 44 Row-Crop Power |
| Engine: | 45 hp
33.6 kW
|
| Drawbar (claimed): | 31 hp
23.1 kW
|
| PTO (claimed): | 44 hp
32.8 kW
|
| Plows: | 3-4
|
| Drawbar (tested): | 39.90 hp
29.8 kW
|
| Belt (tested): | 45.64 hp
34.0 kW
|
| power test details ... |
| Mechanical |
| Steering: | manual
|
| Brakes: | differential mechanical drum
|
| Cab: | Open operator station.
|
| Transmission: | 5-speed unsynchronized gear
|
 Transmission details ... |
| Capacity |
| Fuel: | 19 gal
71.9 L
|
| Aux. fuel: | 5.75 gal
21.8 L
|
| Hydraulic system: | 1.75 gal
6.6 L
|
| Hydraulics |
| Capacity: | 1.75 gal
6.6 L
|
| Pressure: | 1050 psi
72.4 bar
|
| Total flow: | 7.5 gpm
28.4 lpm
|
| Tractor hitch |
| Type: | Massey Hitch-All
|
| Power Take-off (PTO) |
| Rear PTO: | transmission
|
| | live*Live PTO available on late models of the Massey 44.
|
| Rear RPM: | 534
|
| 44 Row-Crop Serial Numbers |
| Location: | Serial number plate on the side of the tractor's main frame, just ahead of the operator platform. May be on left or right.
|
| 1946: | 1001
|
| 1947: | 1002
|
| 1948: | 2048
|
| 1949: | 5318
|
| 1950: | 13822
|
| 1951: | 21815
|
| 1952: | 31275
|
| 1953: | 43700
|
| 1947: | 1001 (44K)
|
| 1948: | 1079 (44K)
|
| 1949: | 1856 (44K)
|
| 1950: | 2599 (44K)
|
| 1951: | 3329 (44K)
|
| 1952: | 4001 (44K)
|
| 1953: | 43700 (44K)
|
| 1949: | 1001 (44D)
|
| 1950: | 1004 (44D)
|
| 1951: | 2483 (44D)
|
| 1952: | 4704 (44D)
|
| 1953: | 43700 (44D)
|
| 1952: | 1001 (44 LP)
|
how to read serial numbers...
|
| Belt Pulley |
| Diameter: | 13.5 inches
34 cm
|
| Width: | 6 inches
15 cm
|
| RPM: | 970
|
| Speed: | 3,050 ft/min
929.64 meters/min
|
| Electrical |
| Charging system: | generator
|
| Batteries: | 1 (gas)
|
| | 2 (diesel)
|
| Battery volts: | 6
|
| Page information |
| Last update: | January 12, 2017
|
| Copyright: | Copyright 2021 TractorData LLC
|
| Contact: | Peter@TractorData.com
|
©2000-2021 - TractorData.com®. Notice: Every attempt is made to ensure the data listed
is accurate. However, differences between sources, incomplete listings,
errors, and data entry mistakes do occur.
Consult official
literature from the manufacturer before attempting any service or repair.
Engine details ...
Full dimensions and tires ...
