    Ford 8830

    Ford 8830 tractor photo
    1990 - 1993   30 Series
    Row-Crop tractor
    Previous model:Ford TW-35
    Smaller:Ford 8730






    Production:

    Manufacturer:Ford
    Factory:Antwerp, Belgium
    Original price (USD):$63,000 (1993)


    Ford 8830 Engine:

       Ford 6.6L 6-cyl diesel
    full engine details ...


    Capacity:

    Fuel:75 gal [283.9 L]
     24.5 gal [92.7 L] (auxiliary tank)
    Steering:2 qts [1.9 L]
    Front hubs:0.8 qts [0.8 L] (each)
    Front diff.:7.9 qts [7.5 L]


    3-Point Hitch:

    Rear Type:3/2
    Control:position and draft control


    Power Take-off (PTO):

    Rear PTO:independent
    Rear RPMs:1000


    Dimensions & Tires:

    Wheelbase:111 inches [281 cm]
    Weight:12995 to 15520 pounds
    Front tire:11.00-16
    Rear tire:18.4/15-38
    full dimensions and tires ...


    8830 Serial Numbers:

    Location:Tractor's rear axle.
    1990: A925439
    1991: A928924
    1992: A930626
    1993: A931957

    how to read serial numbers...



    Ford 8830 Power:

    PTO (claimed):170 hp [126.8 kW]
    Drawbar (tested):145.69 hp [108.6 kW]
    PTO (tested):171.12 hp [127.6 kW]


    Mechanical:

    Chassis:4x2 2WD
     4x4 MFWD 4WD optional
    Steering:hydrostatic power
    Brakes:Power disc
    Cab:Optional cab with heat and A/C


    Hydraulics:

    Type:open center gear pump, dual pumps optional
    Pressure:2500 psi [172.4 bar]
    Valves:2 to 4
    Pump flow:20 gpm [75.7 lpm]
     28.6 gpm [108.3 lpm] (dual pumps)
    SCV flow:16.9 gpm [64.0 lpm]
     19 gpm [71.9 lpm] (dual pumps)
    Steering cap.:2 qts [1.9 L]
    Steering press.:2025 psi [139.6 bar]


    Electrical:

    Ground:negative
    Charging system:alternator
    Charging amps:90


    Battery:

    Number:1
    Volts:12
