Tractors > Ford-New Holland > 8530

Ford-New Holland 8530 - engine

No photo available
1990 - 1993
Row-Crop tractor
more Ford-New Holland 8530 specifications...





Note: the Ford-New Holland model 8530 is the same as the Ford 8530. The following data is from the 8530 listing.


Engine Detail:

 Ford
 diesel
 6-cylinder
 liquid-cooled
 401 ci [6.6 L]
Bore/Stroke:4.40x4.40 inches [112 x 112 mm]
Compression:16.3:1
Rated RPM:2300
Firing order:1-5-3-6-2-4
Oil capacity:19.6 qts [18.5 L]
Coolant capacity:21.2 qts [20.1 L]
 22.4 qts [21.2 L] (with heater)
Intake valve clearance:0.014-0.016 inches [0.356 mm] (cold)
Exhaust valve clearance:0.017-0.019 inches [0.432 mm] (cold)
