Ford 2110 Tests
|
|
| Tractor Tests | |
| NTTL 1509: diesel manual 2WD | |
| NTTL 1510: diesel synchromesh 2WD |
| Nebraska Tractor Test 1509 | |||
| |||
| Nebraska Tractor Test 1509 | |
| Diesel manual 2WD March 30 - April 13, 1984 Link: Nebraska Tractor Test 1509 file | |
| PTO performance | |
| Power at rated engine speed | 34.79 hp 25.9 kW |
| Fuel use | 2.5 gal/hour 9.5 l/hour |
| Power at rated PTO speed | 34.91 hp 26.0 kW |
| Fuel use | 2.5 gal/hour 9.5 l/hour |
| Drawbar performance | |
| Max power | 28.84 hp 21.5 kW |
| Fuel use | 2.4 gal/hour 9.1 l/hour |
| Gear 3-2 used for power test. | |
| Max pull | 3,868 lbs 1754 kg |
| Gear 2-2 used for pull test. | |
| Nebraska Tractor Test 1510 | |||
| |||
| Nebraska Tractor Test 1510 | |
| Diesel synchromesh 2WD March 30 - April 9, 1984 Link: Nebraska Tractor Test 1510 file | |
| PTO performance | |
| Power at rated engine speed | 35.11 hp 26.2 kW |
| Fuel use | 2.5 gal/hour 9.5 l/hour |
| Power at rated PTO speed | 35.56 hp 26.5 kW |
| Fuel use | 2.5 gal/hour 9.5 l/hour |
| Drawbar performance | |
| Max power | 30.10 hp 22.4 kW |
| Fuel use | 2.6 gal/hour 9.8 l/hour |
| Gear 3-2 used for power test. | |
| Max pull | 3,728 lbs 1691 kg |
| Gear 2-3 used for pull test. | |
