J.I. Case 2670 Traction King


J.I. Case 2670 Traction King tractor photo
1974 - 1979
Four-wheel Drive (4WD) tractor
Series:24702670 Traction King2870
4690
Production
Manufacturer:J.I. Case
Type:Four-wheel Drive (4WD) tractor
Factory:Racine, Wisconsin, USA
Total built:5,900
Original price:$50,200 (1979 )
J.I. Case 2670 Power
Engine (gross):256 hp
190.9 kW
Drawbar (claimed):193 hp
143.9 kW
PTO (claimed):221 hp
164.8 kW
Drawbar (tested):189.35 hp
141.2 kW
PTO (tested):219.44 hp
163.6 kW
power test details ...
J.I. Case 2670 Engine
J.I. Case 8.3L 6-cyl diesel
Fuel tank:110 gal
416.4 L
Engine details ...
Mechanical
Chassis:4x4 4WD
Steering:hydrostatic power, four-wheel steering
Brakes:hydraulic wet disc
Cab:Cab standard
Transmission:12-speed partial power shift
Transmission details ...
Hydraulics
Type:open center
Pressure:2050 psi
141.3 bar
Valves:2 to 4
SCV flow:17 gpm
64.3 lpm
Total flow:34 gpm
128.7 lpm
Steering flow:17 gpm
64.3 lpm
Tractor hitch
Rear Type:III
Rear lift (at 24"/610mm):10000 lbs
4536 kg
Power Take-off (PTO)
Rear PTO:independent
Rear RPM:1000
Dimensions & Tires
Wheelbase:102 inches
259 cm
Weight:16370 to 20810 pounds
Front tire:18.4-34
Rear tire:18.4-34
Full dimensions and tires ...
2670 Serial Numbers
1974:8762001
1975:8767001
1976:8792901
1977:8825001
1978:8853001
1979:8853001

how to read serial numbers...
